3-5 TPH Limestone Grinding Plant In Zimbabwe

Raw materials: Limestone
Capacity: 3-5tph
Location: Zimbabwe
The 3-5 t/h limestone grinding plant uses the YGM95 grinding mill as the main machine, and is equipped with PE250×300 jaw crusher, bucket elevator, transfer silo, electromagnetic vibrating feeder, dust collector, powder conveyor, powder collector and other equipment to form a complete grinding production line.

If you have any questions,you can ask customer service online !

Get Quotes leave message

Limestone is mainly composed of calcium carbonate and is a common sedimentary rock that is mostly white or gray. It is an important raw material for the production of cement, lime and concrete, and is also widely used in plastics, rubber, papermaking, coatings and other industries.

YGM raymond grinding mill can be used to grind limestone into the fineness required by users. It has become the best choice for most small and medium-sized grinding plants.

3-5 TPH Limestone Grinding Plant In Zimbabwe

A complete limestone grinding line mainly consists of four processes: crushing, grinding, powder collection and packaging.

If you want to open a 3-5tph soft stone grinding mill plant, the following configuration is recommended:

YGM95 High-pressure Grinding System:

1. Crushing Part: PE250x300 Model Jaw Crusher, Power: 5.5kw, To crush big stones (<130mm) to 5-25mm

2. Bucket Elevator: TH200x7.5M Model, To convey the crushed limestone to the grinding mill

3. Transfer Silo: Buffering the inflow of materials

4. Feeder: GZ2F Model Fully enclosed electromagnetic vibrating feeder

5. YGM Mill: YGM95 Main Mill, Power: 37kw, Powder Classifier: 45kw

6. Dust Removal: Single Cyclone Collector, DMC36 Bag Dust Collector, Blower: 45kw

7. Powder Conveyor: LS200 Screw Conveyor

8. Powder Collecting:

In general, it is recommended to use the finished product bucket to lift it to the finished product silo for collection.

The height of the finished product bucket and the silo capacity are determined by the manufacturer based on the actual situation on site and under the guidance of the manufacturer.

VEST YGM95 grinding machines have been exported to more than 100 countries and regions around the world. It is favored by the majority of users because of its advantages such as high return on investment, energy saving and environmental protection, stable operation and long service life.
